You Asked, We Answered: The Dell NDC Parts Charts!

You Asked, We Answered: The Dell NDC Parts Charts!



Jump to:

Dell 12th Generation PowerEdge NDCs Chart
Dell 13th/14th Gen PowerEdge NDCs Chart



You asked, we answered! We recently wrote about the ins and outs of NICs and were reminded of a question we frequently receive: how on earth do you tell the difference between Dell’s various NDCs? As our friend Mike O’Dell put it,


“One thing that is daunting is the expansive list of NICs & NDC boards that look equivalent (eg 4x1G RJ45) but have very different prices and only Dell bingo numbers to distinguish them. Given the evolution of the Ethernet chips, knowing which part is on the card is *golden*. Is there an xref somewhere for the Dell novitiates?”


Short answer: Unfortunately, no, there isn’t. And searching through countless documents and forums with only a part number in hand definitely doesn’t make it easy to tell the difference between the boards. To save you some time, we put together a few handy charts of Dell’s NDCs for 12th and 13th/14th gen servers, complete with part number, model name, and port configuration.



Dell 12th Generation PowerEdge NDCs

Compatible with Dell R620, R720, R820.

Part Chipset Port Configuration
DELL_0JC10M Broadcom 57840S Quad-Port 10GB SFP+
DELL_0XGRFF Broadcom 57840S Quad-Port 10GB SFP+
DELL_0F6PCP Emulex OneConnect Quad-Port 10GB SFP+
DELL_0XVVY1 QLogic QL41164 Quad-Port 10GB SFP+
DELL_0C63DV Intel X520-DA2 + Intel i350-T2 Dual-Port 10GB SFP+
+ Dual-Port 1GB RJ-45
DELL_0165T0 Broadcom 57800S Dual-Port 10GB SFP+
+ Dual-Port 1GB RJ-45
DELL_0MT09V Broadcom 57800S Dual-Port 10GB RJ-45
+ Dual-Port 1GB RJ-45
DELL_0Y36FR Broadcom 57800S Dual-Port 10GB RJ-45
+ Dual-Port 1GB RJ-45
DELL_0G8RPD Broadcom Netxtreme II 57800-T Dual-Port 10GB RJ-45
+ Dual-Port 1GB RJ-45
DELL_099GTM Intel X540-T2 + Intel i350-T2 Dual-Port 10GB RJ-45
+ Dual-Port 1GB RJ-45
DELL_098493 Intel X540-T2 + Intel i350-T2 Dual-Port 10GB RJ45
+ Dual-Port 1GB RJ-45
DELL_0P71JP Intel X540-T2 + Intel i350-T2 Dual-Port 10GB RJ-45 + Dual-Port 1GB RJ-45
DELL_0FM487 Broadcom 5720 Quad-Port 1GB RJ-45
DELL_0R1XFC Intel i350-T4 Quad-Port 1GB RJ-45


Dell 13th/14th Generation PowerEdge NDCs



All of the cards in our Dell 12th gen chart are compatible with Dell 13th/14th generation servers, as well as a few newer chipsets. However, the 13th and 14th Gen NDCs are not compatible with the 12th Gen servers.



Part Chipset Port Configuration
DELL_0R887V Mellanox ConnectX-4 Dual-Port 25GB SFP28
DELL_0JC10M Broadcom 57840S Quad-Port 10GB SFP+
DELL_0XGRFF Broadcom 57840S Quad-Port 10GB SFP+
DELL_0F6PCP Emulex OneConnect Quad-Port 10GB SFP+
DELL_068M95 Intel X710-DA4 Quad-Port 10GB SFP+
DELL_0XVVY1 QLogic QL41164 Quad-Port 10GB SFP+
DELL_0C63DV Intel X520-DA2 + Intel i350-T2

Dual-Port 10GB SFP+
+ Dual-Port 1GB RJ-45

DELL_0165T0 Broadcom 57800S Dual-Port 10GB SFP+
+ Dual-Port 1GB RJ-45
DELL_06VDPG Intel x710-T2 + I350-T2 Dual-Port 10GB SFP+
+ Dual-Port 1GB RJ-45
DELL_05V6Y4 Qlogic QL41264 Dual-Port 10GB SFP+
+ Dual-Port 1GB RJ-45
DELL_0NWMNX Broadcom 57412 Dual-Port 10GB SFP+
DELL_064PJ8 Intel X550-T4 Quad-Port RJ-45
DELL_0CD2VM Intel X550-T2 + Intel i350-T2
Dual-Port 10GB RJ-45
+ Dual-Port 1GB RJ-45
DELL_01224N Broadcom 57416 Dual-Port 10GB RJ-45
+ Dual-Port 1GB RJ-45
DELL_0MT09V Broadcom 57800S Dual-Port 10GB RJ-45
+ Dual-Port 1GB RJ-45
DELL_0Y36FR Broadcom 57800S Dual-Port 10GB RJ-45
+ Dual-Port 1GB RJ-45
DELL_0G8RPD Broadcom Netxtreme II 57800-T Dual-Port 10GB RJ-45
+ Dual-Port 1GB RJ-45
DELL_099GTM Intel X540-T2 + Intel i350-T2 Dual-Port 10GB RJ-45
+ Dual-Port 1GB RJ-45
DELL_098493 Intel X540-T2 + Intel i350-T2 Dual-Port 10GB RJ-45
+ Dual-Port 1GB RJ-45
DELL_0P71JP Intel X540-T2 + Intel i350-T2 Dual-Port 10GB RJ-45
+ Dual-Port 1GB RJ-45
DELL_0FM487 Broadcom 5720 Quad-Port 1GB RJ-45
DELL_0R1XFC Intel i350-T4 Quad-Port 1GB RJ-45
DELL_0CF4P0* Broadcom 57416* Dual-Port 10GB SFP+*



*DELL_0CF4P0 is only compatible with R440’s.
